Product Name/Title: 3-pole, 100A Modular Switch with Red Toggle
Brand: Hager
SKU: SBR390
Alternatively Known As: Hager SBR390 Switch
Technical Specifications
- Architecture: 3-pole without neutral
- Rated current: 100 A
- Breaking capacity 400 V AC23A: 1692 A
- Rated conditional short-circuit current Icc: 1.20 kA
- Acceptable current rating AC21 category A: 100 A
- Acceptable current rating AC21 category B: 100 A
- Acceptable current rating AC22 category A: 100 A
- Acceptable current rating AC22 category B: 100 A
- Acceptable current rating AC23 category A: 40 A
- Acceptable current rating AC23 category B: 40 A
- Rated short-circuit making capacity Icm: 1.69 kA
- Rated short-time withstand current Icw 1s: 1.20 kA
- Nominal tightening torque: 3.60 Nm
- Type of bottom connection: Screw terminal
- Rated operational voltage Ue: 400 V AC
- Rated insulation voltage Ui: 440 V
- Rated impulse withstand voltage Uimp: 6000 V
- Number of modules: 3
- Ingress Protection (IP) class: IP20
- Frequency: 50 - 60 Hz
- Operating temperature: -20 - 70 °C
- Storage/transport temperature: -40 - 80 °C
- Cross-section flexible conductor: 6 - 35 mm²
- Cross-section rigid conductor: 6 - 50 mm²
- Number of mechanical operations: 40000
- Electrical durability at nominal load in AC21: 2500 cycles
- Electrical durability at nominal load in AC22: 2500 cycles
- Total power loss under IN: 16.50 W
- Power loss per pole at In: 5.50 W
- Down and top connection alignment: Aligned terminal
- Dimensions (H x L x W): 83mm x 52.50mm x 68mm
- Weight: 0.5 kg
Key Features
- Modular design for versatile installation
- High rated current capacity
- Robust insulation and protection
- Long mechanical and electrical lifespan
Professional Installation Requirements
- Professional installation by a certified electrician is required.
Applications
- Industrial electrical setups
- Commercial power distribution systems
Standards & Compliance
- Complies with IEC 60947-3 standards
Environmental Benefits
- Efficient power management reduces energy loss
Warranty Information
2-year warranty against manufacturing defects.
Available Now
The 3-pole, 100A Modular Switch with Red Toggle is available now for immediate purchase. Ideal for industrial and commercial power distribution solutions.
