Product Name/Title: 4-pole, 100A Modular Switch with Red Toggle
Brand: Hager
SKU: SBR490
Alternatively Known As: 4P 100A Red Toggle Switch
Technical Specifications
- Number of poles: 4
- Rated current: 100A
- Rated operational voltage Ue: 400V
- Rated insulation voltage Ui: 440V
- Breaking capacity 400 V AC23A: 1692A
- Rated conditional short-circuit current Icc: 1,20 kA
- Rated short-circuit making capacity Icm: 1,69 kA
- Ingress Protection (IP) class: IP20
- Nominal tightening torque: 3,60 Nm
- Frequency: 50 - 60 Hz
- Operating temperature: -20 - 70 °C
- Dimensions (H x L x W): 83mm x 69mm x 70mm
- Weight: 0.75 kg
Key Features
- High current rating of 100A suitable for heavy-duty applications.
- Robust design with IP20 ingress protection.
- Modular 4-pole switch configuration for enhanced reliability.
- Aligned top and bottom connections for easy installation.
Professional Installation Requirements
- Requires installation by a qualified electrician to ensure compliance with safety standards.
Applications
- Industrial power distribution systems.
- Commercial electrical installations.
- General heavy-duty electrical systems.
Standards & Compliance
- Compliant with IEC 60947-3 for switchgear and controlgear standards.
Environmental Benefits
- Efficient design reducing energy waste.
- Longevity minimizes replacement and waste.
Warranty Information
1-year warranty against manufacturing defects.
Available Now
The Hager 4-pole, 100A Modular Switch with Red Toggle is available for immediate purchase. Ideal for industrial applications requiring robust electrical solutions.
