440RM23143

AB 440R MSR Safety Relay 24VAC/DC 1NC/2NC LC-IN 5NO-SFTY AM/MM 0.15-3S


$605.50 List price: $804.10
+

Weight: 0.350 kg

Product Name/Title: AB 440R MSR Safety Relay 24VAC/DC 1NC/2NC LC-IN 5NO-SFTY AM/MM 0.15-3S

Brand: NHP

SKU: 440RM23143

Alternatively Known As: Safety Relay, MSR Relay, Monitoring Relay

Technical Specifications
  • Rated operation current: 7 A
  • Control supply voltage: 24 V AC/DC
  • Safety category: 4 (according to EN ISO 13849-1)
  • Degree of protection: IP40
  • Ambient temperature: -5 to 55 °C
  • Performance level: Level e (according to EN ISO 13849-1)
  • Rail mounting possible: Yes
  • Dimensions (H x L x W): 99mm x 114.5mm x 45mm
  • Weight: 0.35 kg
Key Features
  • Suitable for monitoring of position switches, emergency stop circuits, valves, optoelectronic protection equipment, tactile sensors, magnetic switches, and proximity switches.
  • Rated operation current of 7 A with multiple output configurations.
Professional Installation Requirements
  • Professional installation by a qualified technician is recommended for optimal safety.
Applications
  • Industrial: Safety monitoring for machinery and equipment
  • Commercial: Emergency stop circuits and safety systems
Standards & Compliance
  • Complies with relevant safety standards for industrial applications.
Environmental Benefits
  • Designed to enhance safety in industrial environments.
Warranty Information

1 year warranty against manufacturing defects.

Available Now

The AB 440R MSR Safety Relay 24VAC/DC is available now for immediate purchase. Ideal for safety monitoring in industrial and commercial applications.
