AB 889D Cordset Cable PVC Red 4 Pin 18AWG DC Micro Female Straight M12 Unshielded 20m


$178.90 List price: $237.60
+

Weight: 1.500 kg

Product Name/Title: AB 889D Cordset Cable PVC Red 4 Pin 18AWG DC Micro Female Straight M12 Unshielded 20m

Brand: NHP

SKU: 889DF4NE20

Alternatively Known As: M12 Micro Connector Cable, 4 Pin DC Cable, PVC Connector Cable

Technical Specifications
  • Rated Current: 4 A
  • Rated Voltage: 250 V
  • Number of Poles: 4
  • Type of Plug: Female (bus)
  • Material Housing: Plastic
  • Coating Housing: Uncoated
  • Material Core Insulation: Other
  • Material of Contact Surface: Gold
  • Degree of Protection: IP69K
  • Mounting Method: Freely positionable
  • AWG Size: 18
  • Cable Diameter: 14 mm
  • Cable Length: 20000 mm
  • Operating Temperature: -20-105 °C
  • Dimensions (H x L x W): 14mm x 20000mm x 14mm
  • Weight: 1.5 kg
Key Features
  • 4-pin female connector for secure connections.
  • IP69K rated for high protection against dust and water.
  • Operating temperature range of -20 to 105 °C.
Professional Installation Requirements
  • Professional installation is recommended for optimal performance and safety.
Applications
  • Industrial: Automation systems, machinery connections
  • Commercial: Equipment requiring reliable power connections
Standards & Compliance
  • Complies with AS/NZS 3820 for essential safety requirements for electrical equipment.
Environmental Benefits
  • Complies with relevant safety and performance standards.
Warranty Information

1 year warranty against manufacturing defects.

Available Now

The AB 889D Cordset Cable PVC Red 4 Pin 18AWG DC Micro Female Straight M12 Unshielded 20m is available now for immediate purchase. Ideal for industrial and commercial applications requiring reliable power connections.

Non-Returnable & Non-Cancellable
