AB 889D Cordset PVC Red 4 Pin 18AWG DC Micro Male Straight DC Micro Female Straight M12 0.6m


$65.20 List price: $86.60
+

Weight: 0.300 kg

Product Name/Title: AB 889D Cordset PVC Red 4 Pin 18AWG DC Micro Male Straight DC Micro Female Straight M12 0.6m

Brand: NHP

SKU: 889DF4NEDM0M6

Alternatively Known As: DC Micro Connector, M12 Connector, 4 Pin Connector

Technical Specifications
  • Rated Current: 4 A
  • Rated Voltage: 250 V
  • Number of Poles: 4
  • Type of Plug: Female (bus)
  • Material Housing: Plastic
  • Coating Housing: Uncoated
  • Material Core Insulation: Other
  • Material of Contact Surface: Gold
  • Degree of Protection: IP69K
  • AWG Size: 18
  • Cable Length: 600 mm
  • Screw-in Thread: M12
  • Operating Temperature: -20-105 °C
  • Dimensions (H x L x W): n/a mm x 600mm x n/a mm
  • Weight: 0.3 kg
Key Features
  • Rated current of 4 A and voltage of 250 V.
  • IP69K protection rating for high durability.
  • Freely positionable mounting method.
Professional Installation Requirements
  • Professional installation is recommended for optimal performance and safety.
Applications
  • Industrial: Automation and control systems
  • Commercial: Equipment requiring reliable power connections
  • General: Any application needing a durable DC micro connector
Standards & Compliance
  • Complies with AS/NZS 3820 for essential safety requirements for electrical equipment.
Environmental Benefits
  • Durable materials reduce the need for frequent replacements, minimizing waste.
Warranty Information

1 year warranty against manufacturing defects.

Available Now

The AB 889D Cordset PVC Red 4 Pin 18AWG DC Micro Connector is available now for immediate purchase. Ideal for industrial and commercial applications requiring reliable power connections.
