AB 889D Cordset PVC Red 8 Pin 22AWG DC Micro Male Straight DC Micro Female Straight M12 0.2m


$121.60 List price: $161.50
+

Weight: 0.200 kg

Product Name/Title: AB 889D Cordset PVC Red 8 Pin 22AWG DC Micro Male Straight DC Micro Female Straight M12 0.2m

Brand: NHP

SKU: 889DF8NBDM0M3

Alternatively Known As: DC Micro Connector, 8 Pin Connector, M12 Connector

Technical Specifications
  • Rated Current: 1.5 A
  • Rated Voltage: 30 V
  • Number of Poles: 8
  • Type of Plug: Female (bus)
  • Material Housing: Plastic
  • Coating Housing: Uncoated
  • Material Core Insulation: Other
  • Material of Contact Surface: Gold
  • Degree of Protection: IP69K
  • Mounting Method: Freely positionable
  • AWG Size: 24
  • Cable Diameter: 14 mm
  • Cable Length: 300 mm
  • Screw-in Thread: M12
  • Operating Temperature: -20-80 °C
  • Dimensions (H x L x W): 14mm x 300mm x 14mm
  • Weight: 0.2 kg
Key Features
  • 8-pin configuration for versatile connectivity.
  • IP69K rated for high protection against dust and water.
Professional Installation Requirements
  • Professional installation is recommended for optimal performance.
Applications
  • Industrial: Automation and control systems
  • Commercial: Machinery and equipment connections
Standards & Compliance
  • Complies with AS/NZS 3820 for essential safety requirements for electrical equipment.
Environmental Benefits
  • Complies with AS/NZS 3820 for essential safety requirements for electrical equipment.
Warranty Information

1 year warranty against manufacturing defects.

Available Now

The AB 889D Cordset PVC Red 8 Pin 22AWG DC Micro is available now for immediate purchase. Ideal for industrial and commercial applications.
