Product Name/Title: Acti9, Double control input auxiliary
Brand: Clipsal
SKU: A9C18308
Alternatively Known As: Acti9 Double Control Input Module, Acti9 Auxiliary Switch
- Control circuit voltage: 230...240 V AC 50/60 Hz.
- Maximum output current: 0.2 A holding, 2 A inrush.
- Hold-in power consumption: 3 VA.
- Overvoltage category: III.
- Rated insulation voltage: 440 V.
- Rated impulse withstand voltage: 4 kV.
- Dimensions (H x L x W): 81mm x 60mm x 18mm
- Weight: 0.086 kg
- Fixed mounting mode on the left of CT.
- DIN rail mounting support.
- IP20 protection rating.
- Professional installation by a qualified electrician is recommended for optimal safety.
- Small commercial and residential applications.
- Complies with IEC/EN 61095.
- Packaging without single-use plastic.
18 months warranty.
The Clipsal Acti9 Double Control Input Auxiliary is available now for immediate purchase. Ideal for small commercial and residential applications.
