100FA13

Allen-Bradley 100C Auxiliary Contact with 1NO Contact and 3NC Contact Front Mount


$89.50 List price: $118.80
+

Weight: 0.300 kg

Product Name/Title: Allen-Bradley 100C Auxiliary Contact with 1NO Contact and 3NC Contact Front Mount

Brand: NHP

SKU: 100FA13

Alternatively Known As: Auxiliary Contact Block, Contactor Accessory, 100C Contact Block

Technical Specifications
  • Number of Contacts: 1 NO, 3 NC
  • Rated Insulation Voltage: 690 V
  • Rated Operation Current at 40°C: 10 A
  • Rated Operation Current at AC 15 (24 V): 6 A
  • Rated Operation Current at AC 15 (120 V): 6 A
  • Rated Operation Current at AC 15 (240 V): 5 A
  • Rated Operation Current at AC 15 (400 V): 3 A
  • Rated Operation Current at DC (12-24 V): 12 A
  • Rated Operation Current at DC (12-110 V): 3.5 A
  • Rated Operation Current at DC (12-220 V): 0.55 A
  • Rated Operation Current at DC (13-24 V): 5 A
  • Rated Operation Current at DC (13-110 V): 1.2 A
  • Rated Operation Current at DC (13-220 V): 0.6 A
  • Minimum Contact Rating Current: 5 mA
  • Minimum Contact Rating Voltage: 17 V
  • Rated Operation Current at AC 15 (230 V): 5.5 A
  • Mounting Method: Top mounting
  • Dimensions (H x L x W): 100mm x 75mm x 50mm
  • Weight: 0.3 kg
Key Features
  • 1 Normally Open (NO) contact and 3 Normally Closed (NC) contacts.
  • Rated insulation voltage of 690 V.
  • Top mounting method for easy installation.
Professional Installation Requirements
  • Professional installation by a qualified electrician is recommended for optimal safety.
Applications
  • Industrial: Used in various control circuits and automation systems.
  • Commercial: Suitable for HVAC systems and machinery control.
Standards & Compliance
  • Complies with AS/NZS 3000 for wiring rules and electrical installation.
Environmental Benefits
  • Complies with AS/NZS 3820 for essential safety requirements for electrical equipment.
Warranty Information

1 year warranty against manufacturing defects.

Available Now

The Allen-Bradley 100C Auxiliary Contact is available now for immediate purchase. Ideal for industrial and commercial applications requiring reliable control solutions.

Non-Returnable & Non-Cancellable
