Product Name/Title: Allen-Bradley 100C Auxiliary Contact with 3NO Contacts and 1NC Contact Front Mount
Brand: NHP
SKU: 100FA31
Alternatively Known As: Auxiliary Contact Block, Contactor Auxiliary Contact
Technical Specifications
- Number of NO contacts: 3
- Number of NC contacts: 1
- Rated insulation voltage: 690 V
- Rated operation current at 40°C: 10 A
- Rated operation current at AC 15, 24 V: 6 A
- Rated operation current at AC 15, 120 V: 6 A
- Rated operation current at AC 15, 240 V: 5 A
- Rated operation current at AC 15, 400 V: 3 A
- Rated operation current at DC 12-24 V: 12 A
- Rated operation current at DC 12-110 V: 3.5 A
- Rated operation current at DC 12-220 V: 0.55 A
- Rated operation current at DC 13-24 V: 5 A
- Rated operation current at DC 13-110 V: 1.2 A
- Rated operation current at DC 13-220 V: 0.6 A
- Minimum contact rating current: 5 mA
- Minimum contact rating voltage: 17 V
- Rated operation current at AC 15, 230 V: 5.5 A
- Dimensions (H x L x W): 50mm x 100mm x 100mm
- Weight: 0.5 kg
Key Features
- 3 Normally Open (NO) contacts and 1 Normally Closed (NC) contact.
- Rated insulation voltage of 690 V.
- Top mounting method for easy installation.
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Industrial: Automation systems, control panels
- Commercial: Electrical installations requiring auxiliary contacts
Standards & Compliance
- Complies with AS/NZS 3820 for essential safety requirements for electrical equipment.
Environmental Benefits
- Standard compliance ensures safety and performance in electrical applications.
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The Allen-Bradley 100C Auxiliary Contact with 3NO and 1NC Contact is available now for immediate purchase. Ideal for industrial and commercial electrical applications.
