100FA40

Allen-Bradley 100C Auxiliary Contact with 4NO Contacts Front Mount


$87.70 List price: $116.50
+

Weight: 0.500 kg

Product Name/Title: Allen-Bradley 100C Auxiliary Contact with 4NO Contacts Front Mount

Brand: NHP

SKU: 100FA40

Alternatively Known As: Auxiliary Contact Block, 100C Contact Block

Technical Specifications
  • Number of contacts: 4 NO
  • Rated insulation voltage: 690 V
  • Rated operation current at 40°C: 10 A
  • Rated operation current at AC 15 (24 V): 6 A
  • Rated operation current at AC 15 (120 V): 6 A
  • Rated operation current at AC 15 (240 V): 5 A
  • Rated operation current at AC 15 (400 V): 3 A
  • Rated operation current at DC (12-24 V): 12 A
  • Rated operation current at DC (12-110 V): 3.5 A
  • Rated operation current at DC (12-220 V): 0.55 A
  • Rated operation current at DC (13-24 V): 5 A
  • Rated operation current at DC (13-110 V): 1.2 A
  • Rated operation current at DC (13-220 V): 0.6 A
  • Minimum contact rating current: 5 mA
  • Minimum contact rating voltage: 17 V
  • Rated operation current at AC 15 (230 V): 5.5 A
  • Mounting method: Top mounting
  • Dimensions (H x L x W): 50mm x 100mm x 100mm
  • Weight: 0.5 kg
Key Features
  • 4 Normally Open (NO) contacts for versatile applications.
  • Rated insulation voltage of 690 V for high-performance use.
  • Top mounting method for easy installation.
Professional Installation Requirements
  • Professional installation by a qualified electrician is recommended for optimal safety.
Applications
  • Industrial: Automation systems, control panels
  • Commercial: Electrical installations requiring auxiliary contacts
Standards & Compliance
  • Complies with relevant Australian standards for electrical safety.
Environmental Benefits
  • Designed for energy efficiency and long-lasting performance.
Warranty Information

1 year warranty against manufacturing defects.

Available Now

The Allen-Bradley 100C Auxiliary Contact with 4NO Contacts Front Mount is available now for immediate purchase. Ideal for industrial and commercial electrical installations.
