100KFA13E

Allen-Bradley 100K Auxiliary Contact with 1NO Contact and 3NC Contact Front Mount for 100K and 700K


$84.00 List price: $111.60
+

Weight: 0.500 kg

Product Name/Title: Allen-Bradley 100K Auxiliary Contact with 1NO Contact and 3NC Contact Front Mount for 100K and 700K

Brand: NHP

SKU: 100KFA13E

Alternatively Known As: Auxiliary Contact Block, Mini Auxiliary Contact, 100KFA13E

Technical Specifications
  • Number of Contacts: 1 NO, 3 NC
  • Rated Insulation Voltage: 690 V
  • Rated Operation Current at 40°C: 10 A
  • Rated Operation Current at AC 15 (24V): 3 A
  • Rated Operation Current at AC 15 (120V): 3 A
  • Rated Operation Current at AC 15 (240V): 2 A
  • Rated Operation Current at AC 15 (400V): 1.2 A
  • Rated Operation Current at DC 13 (24V): 2.3 A
  • Rated Operation Current at DC 13 (110V): 0.55 A
  • Rated Operation Current at DC 13 (220V): 0.27 A
  • Min Contact Rating Current: 2 mA
  • Min Contact Rating Voltage: 15 V
  • Rated Operation Current at AC 15 (230V): 2 A
  • Mounting Method: Top mounting
  • Dimensions (H x L x W): 100mm x 75mm x 50mm
  • Weight: 0.5 kg
Key Features
  • 1 Normally Open (NO) contact and 3 Normally Closed (NC) contacts.
  • Rated insulation voltage of 690 V.
  • Top mounting method for easy installation.
Professional Installation Requirements
  • Professional installation by a qualified electrician is recommended for optimal safety.
Applications
  • Industrial: Control panels, machinery, and automation systems
  • Commercial: HVAC systems, lighting control, and motor control
Standards & Compliance
  • Complies with AS/NZS 60950 for safety of IT and communication equipment.
Environmental Benefits
  • Durable design reduces the need for frequent replacements, minimizing waste.
Warranty Information

1 year warranty against manufacturing defects.

Available Now

The Allen-Bradley 100K Auxiliary Contact is available now for immediate purchase. Ideal for industrial and commercial applications requiring reliable control solutions.

Non-Returnable & Non-Cancellable
