Product Name/Title: Allen-Bradley 100K Contactor Mini 5.5kW 3Pole 24VDC Coil with Diode 1NC Contact Auxiliary
Brand: NHP
SKU: 100K12DJ01
Alternatively Known As: Mini Contactor, Power Contactor, 3 Pole Contactor
Technical Specifications
- Number of Normally Open Contacts: 3
- Number of Normally Closed Contacts: 0
- Rated Operation Current at AC 3, 400V: 11.5 A
- Rated Operation Power at AC 3, 400V: 5.5 kW
- Rated Operation Current at AC 1, 400V: 20 A
- Max Rated Operation Voltage: 690 V
- Control Supply Voltage: 24 V DC
- Number of Auxiliary Contacts (Normally Closed): 1
- Rated Operation Current at AC 3, 690V: 6.7 A
- Rated Operation Power at AC 3, 690V: 5.5 kW
- Rated Operation Power at AC 4, 400V: 1.1 kW
- Power Consumption DC Coil Pickup: 3 W
- Power Consumption DC Coil Hold In: 3 W
- Type of Electrical Connection: Screw connection
- Rated Operation Current at AC 4, 400V: 3.6 A
- Mounting Method: DIN-rail/screw
- Dimensions (H x L x W): 56mm x 53mm x 44.9mm
- Weight: 0.2 kg
Key Features
- 3 Pole contactor with 5.5 kW rated operation power.
- 24V DC coil with diode for enhanced performance.
- IP20 protection degree suitable for indoor use.
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Industrial: Automation systems, motor control applications
- Commercial: HVAC systems, lighting control
Standards & Compliance
- Complies with relevant Australian standards for electrical equipment.
Environmental Benefits
- Energy-efficient design reduces power consumption.
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The Allen-Bradley 100K Contactor Mini 5.5kW 3Pole 24VDC Coil with Diode is available now for immediate purchase. Ideal for industrial and commercial applications.
