Product Name/Title: Allen-Bradley 140G MCCB G Frame 70kA 4P 70A Fixed Thermal Magnetic
Brand: NHP
SKU: 140GG6C4C70
Alternatively Known As: Moulded Case Circuit Breaker, MCCB, Circuit Breaker 70A
Technical Specifications
- Rated ultimate short circuit breaking capacity: 70 kA at 415 V
- Rated service short circuit breaking capacity: 35 kA at 415 V
- Rated insulation voltage: 800 V
- Rated frequency: 50-60 Hz
- Electrical life: 8000 cycles
- Mechanical life: 25000 cycles
- Power loss: 14.7 W
- Reverse connection of supply possible: Yes
- DIN rail mounting optional: Yes
- Dimensions (H x L x W): 130mm x 70mm x 101.2mm
- Weight: 1.4 kg
Key Features
- Rated current: 70 A
- 4 poles for versatile applications
- Fixed thermal and magnetic trip unit for reliable protection
- High breaking capacity of 70 kA at 415 V
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Industrial: Power distribution and protection in manufacturing facilities
- Commercial: Electrical systems in commercial buildings
- General: Any application requiring reliable circuit protection
Standards & Compliance
- Complies with relevant Australian standards for electrical safety.
Environmental Benefits
- Designed for high efficiency and reliability in electrical systems.
Warranty Information
Standard warranty applies, please check with the manufacturer for details.
Available Now
The Allen-Bradley 140G MCCB G Frame 70kA 4P 70A Fixed Thermal Magnetic is available now for immediate purchase. Ideal for industrial and commercial electrical systems.
