1606XLP100E

Allen-Bradley 1606 Power Supply Compact 1Phase 100 to 240V AC to 24 to 28V DC 100W 4.2A


$452.40 List price: $600.80
+

Weight: 0.360 kg

Product Name/Title: Allen-Bradley 1606 Power Supply Compact 1Phase 100 to 240V AC to 24 to 28V DC 100W 4.2A

Brand: NHP

SKU: 1606XLP100E

Alternatively Known As: Switched Mode Power Supply, DC Power Supply, 1606XLP100E

Technical Specifications
  • Voltage Type: AC/DC
  • Rated Supply Voltage: 100-240 V AC, 220-375 V DC
  • Frequency: 50-60 Hz
  • Nominal Current In: 1 A
  • Max Starting Current: 37 A
  • Output Voltage: 24-28 V
  • Max Output Current: 4.2 A
  • Power Output: 100 W
  • Power Consumption: 11.4 VA
  • Efficiency: 90 %
  • Type of Electric Connection: Spring clamp connection
  • Degree of Protection: IP20
  • Operating Temperature: -10-70 °C
  • Dimensions (H x L x W): 75mm x 103mm x 73mm
  • Weight: 0.36 kg
Key Features
  • Switched Mode Power Supply with high efficiency of 90%.
  • Adjustable secondary output voltage.
  • LED indication for operational status.
  • Compact design suitable for rail and wall mounting.
Professional Installation Requirements
  • Professional installation by a qualified electrician is recommended for optimal safety.
Applications
  • Industrial: Automation systems, control panels
  • Commercial: Power supply for various electronic devices
Standards & Compliance
  • Complies with AS/NZS 3820 for essential safety requirements for electrical equipment.
Environmental Benefits
  • Designed for energy efficiency and reduced environmental impact.
Warranty Information

1 year warranty against manufacturing defects.

Available Now

The Allen-Bradley 1606 Power Supply is available now for immediate purchase. Ideal for industrial and commercial applications requiring reliable power conversion.
