Product Name/Title: Allen-Bradley 700-HK General Purpose Slim Line Relay 8A 2 CO DPDT 24V AC Coil with Pilot Light
Brand: NHP
SKU: 700HK32A244
Alternatively Known As: Slim Line Relay, General Purpose Relay, DPDT Relay
Technical Specifications
- Nominal Current: 8 A
- Nominal Voltage AC: 250 V
- Number of Contacts: 2 CO DPDT
- Rated Switching Power at AC-1: 2000 VA
- Rated Switching Power at AC-15 (230 V): 350 VA
- Breaking Capacity at DC-1 (30 V): 6 A
- Control Supply Voltage: 24 V AC
- Degree of Protection: IP20
- Operating Temperature: -40 to 70 °C
- Mechanical Life: 10,000,000 cycles
- Max Shock Acceleration: 50 g
- Max Vibration Acceleration: 5 m/s²
- Max Vibration Frequency Operational: 2000 Hz
- Dimensions (H x L x W): 29mm x 32.8mm x 12.4mm
- Weight: 0.1 kg
Key Features
- General purpose relay with LED indication.
- Plug-in connection for easy installation.
- High electrical life of 30,000 cycles.
Professional Installation Requirements
- Professional installation is recommended for optimal performance and safety.
Applications
- Industrial: Automation systems, control panels
- Commercial: HVAC systems, lighting control
- General: Any application requiring reliable switching
Standards & Compliance
- Complies with AS/NZS 60950 for safety of IT and communication equipment.
Environmental Benefits
- Durable design reduces the need for frequent replacements, minimizing waste.
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The Allen-Bradley 700-HK General Purpose Slim Line Relay is available now for immediate purchase. Ideal for industrial and commercial applications requiring reliable switching.
