MCB11063D

Circuit Breaker 1 Pole 10kA 63A


$7.10 List price: $9.30
+

Weight: 0.500 kg

Product Name/Title: Circuit Breaker 1 Pole 10kA 63A

Brand: Connected Switchgear

SKU: MCB11063D

Alternatively Known As: 1 Pole Circuit Breaker, 10kA MCB, Miniature Circuit Breaker

Technical Specifications
  • Product Code: MCB11063D
  • Voltage: 240V AC
  • Amperage: 63A
  • Power: 10kA
  • Poles: 1 Pole
  • Configuration: D Curve
  • Approval: Energy Safe Victoria
  • Dimensions (H x L x W): 85mm x 70mm x 18mm
  • Weight: 0.5 kg
Key Features
  • 10kA breaking capacity suitable for commercial and heavy industrial applications.
  • 18mm pole width with ON/OFF indicators.
  • 35mm DIN rail mounting and lockable toggles.
  • Pin/fork type busbar terminal connection.
Professional Installation Requirements
  • Professional installation by an authorised electrician is recommended for optimal safety.
Applications
  • Commercial: Heavy industrial applications requiring reliable circuit protection.
  • General: Any application needing overload and short circuit protection.
Standards & Compliance
  • Complies with AS/NZS 60898.1 and AS/NZS 60947.2 for safety and performance standards.
Environmental Benefits
  • High-grade components ensure longevity and reduce waste from frequent replacements.
Warranty Information

5 Year In House Warranty covering replacement and installation by an authorised electrician.

Available Now

The Circuit Breaker 1 Pole 10kA 63A is available now for immediate purchase. Ideal for commercial and industrial applications requiring reliable circuit protection.

MCB11063D (MCBs.pdf, 1,201 Kb) [Download]
