Product Name/Title: Circuit Breaker 2 Pole 10kA 125A
Brand: Connected Switchgear
SKU: MCB210125C
Alternatively Known As: Miniature Circuit Breaker, MCB, Circuit Protection Device
- Product Code: MCB210125C
- Voltage: 240V AC
- Amperage: 125A
- Power: 10kA
- Poles: 2 Pole
- Configuration: C Curve
- Approval: Energy Safe Victoria
- Dimensions (H x L x W): 85mm x 100mm x 54mm
- Weight: 1.0 kg
- 10kA breaking capacity for high performance.
- 27mm pole width with ON/OFF indicators.
- Compatible with up to 35mm² cable.
- 35mm DIN rail mounting with lockable toggles.
- Pin/fork type busbar terminal connection.
- Professional installation by a qualified electrician is recommended for optimal safety.
- Commercial: Heavy industrial applications requiring reliable circuit protection.
- General: Any installation needing overload and short circuit protection.
- Complies with AS/NZS 60898.1 and AS/NZS 60947.2 for safety and performance standards.
- Durable design reduces waste and promotes long-term use.
5 Year In House Warranty covering replacement and installation by an authorised electrician.
The Circuit Breaker 2 Pole 10kA 125A is available now for immediate purchase. Ideal for commercial and heavy industrial applications.
