MCB2616C

Circuit Breaker 2 Pole 6kA 16A


$12.50 List price: $16.30
+

Weight: 0.500 kg

Product Name/Title: Circuit Breaker 2 Pole 6kA 16A

Brand: Connected Switchgear

SKU: MCB2616C

Alternatively Known As: Miniature Circuit Breaker, MCB, Circuit Protection Device

Technical Specifications
  • Product Code: MCB2616C
  • Voltage: 240V/415V AC
  • Amperage: 16A
  • Power: 6kA
  • Poles: 2 Pole
  • Configuration: C Curve
  • Compliance: AS/NZS 60898.1:2004
  • Dimensions (H x L x W): 85mm x 70mm x 18mm
  • Weight: 0.5 kg
Key Features
  • 6kA breaking capacity for reliable overload and short circuit protection.
  • 18mm pole width with ON/OFF indicators.
  • 35mm DIN rail mounting and lockable toggles.
  • Pin/fork type busbar terminal connection.
Professional Installation Requirements
  • Professional installation by a qualified electrician is recommended for optimal safety.
Applications
  • Commercial: Industrial applications requiring circuit protection.
  • General: Suitable for various electrical installations.
Standards & Compliance
  • Complies with AS/NZS 60898.1 and AS/NZS 60947.2 for safety and performance standards.
Environmental Benefits
  • Durable design reduces the need for frequent replacements, minimizing waste.
Warranty Information

5 years warranty covering replacement and installation by an authorised electrician.

Available Now

The Circuit Breaker 2 Pole 6kA 16A is available now for immediate purchase. Ideal for commercial and industrial applications requiring reliable circuit protection.

MCB2616C (MCBs.pdf, 1,201 Kb) [Download]
