MCB2650D

Circuit Breaker 2 Pole 6kA 50A


$14.90 List price: $19.40
+

Weight: 0.500 kg

Product Name/Title: Circuit Breaker 2 Pole 6kA 50A

Brand: Connected Switchgear

SKU: MCB2650D

Alternatively Known As: 50A Circuit Breaker, 2 Pole MCB, Miniature Circuit Breaker, FUSION Series MCB

Technical Specifications
  • Product Code: MCB2650D
  • Voltage: 240V/415V AC
  • Amperage: 50A
  • Power: 6kA
  • Poles: 2 Pole
  • Configuration: D Curve
  • Compliance: AS/NZS 60898.1:2004
  • Dimensions (H x L x W): 90mm x 70mm x 36mm
  • Weight: 0.5 kg
Key Features
  • 6kA breaking capacity for reliable protection.
  • 18mm pole width with ON/OFF indicators.
  • Compatible with up to 25mm² cable.
  • 35mm DIN rail mounting and lockable toggles.
  • Pin/fork type busbar terminal connection.
Professional Installation Requirements
  • Professional installation by a qualified electrician is recommended for optimal safety.
Applications
  • Commercial: Suitable for industrial applications requiring circuit protection.
  • General: Ideal for any installation needing reliable overload and short circuit protection.
Standards & Compliance
  • Complies with AS/NZS 60898.1 and AS/NZS 60947.2 for safety and performance standards.
Environmental Benefits
  • Durable design reduces the need for frequent replacements, minimizing waste.
Warranty Information

5 years warranty covering replacement and installation by an authorised electrician.

Available Now

The Circuit Breaker 2 Pole 6kA 50A is available now for immediate purchase. Ideal for commercial and industrial applications requiring reliable circuit protection.

MCB2650D (MCBs.pdf, 1,201 Kb) [Download]
