Product Name/Title: Contactor 40A, 4NC, 230V~50Hz
Brand: Hager
SKU: ESC441
Alternatively Known As: Hager Contactor 40A
Technical Specifications
- Type of contacts: 4NC
- Number of contacts: 4
- Cross-section flexible conductor: 1.5 - 16 mm²
- Cross-section rigid conductor: 1.5 - 25 mm²
- Rated current: 40 A
- Number of modules: 3
- Frequency: 50 - 50 Hz
- Rated impulse withstand voltage Uimp: 4000 V
- Rated insulation voltage Ui: 440 V
- Command voltage AC: 230 - 230 V
- Command voltage DC: 0 - 0 V
- Operating temperature: -10 - 50 °C
- Storage/transport temperature: -40 - 80 °C
- Number of mechanical operations: 100000
- Electric endurance in number of cycles: 30000
- Total power loss under IN: 12.80 W
- Inrush power absorbed: 62.50 VA
- Height: 85 mm
- Width: 54 mm
- Depth: 60 mm
- Number of NO contacts: 0
- Number of NC contacts: 4
- With switch for manual switch: No
- Dimensions (H x L x W): 85mm x 60mm x 54mm
- Weight: 0.4 kg
Key Features
- Reliable switching for electrical circuits
- Supports flexible and rigid conductor connections
- Durable with high electric endurance
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Residential and commercial electrical installations
- Switching circuits requiring high current capability
Standards & Compliance
- Complies with relevant Australian electrical standards.
Environmental Benefits
- Efficient power loss management
- Long-lasting mechanical operations reduce waste
Warranty Information
5 years warranty against manufacturing defects.
Available Now
Available for immediate purchase. Ideal for residential and commercial circuit switching needs.
