Application
Smart lighting controls for residential and commercial applications
Design Specifications
- Push button control trailing or leading edge digital dimming
- Multiple-location dimming by connecting SDD300UM with any number of secondary dimmers SDD300US can be achieved. NOTE: the total length of the remote wire (>0.5mm2) used to interconnect all of the SDD300US should not exceed 50 metres.
- Fit most popular switch plates
- Overheating and over current protection, full short circuit protection
- Programmable minimum brightness level
- Compliant to AS/NZS60669.2.1, Dimensions (LWH mm) - 44 x 23 x 23.
