Product Name/Title: Finder 60 Series General Purpose Relay 10A 3CO 220V DC Coil with PB plus Mechanical Indicator
Brand: NHP
SKU: 6013220VDCRLY
Alternatively Known As: General Purpose Relay, Switching Relay, Panel Mount Relay
Technical Specifications
- Nominal Current: 10 A
- Nominal Voltage AC: 250 V
- Max Rated Operation Voltage (UE AC): 400 V
- Rated Switching Power at AC-1: 2500 VA
- Rated Switching Power at AC-15 (230 V): 500 VA
- Breaking Capacity at DC-1 (30 V): 10 A
- Breaking Capacity at DC-1 (110 V): 0.4 A
- Control Supply Voltage (US) at DC: 220 V
- Electrical Life at UN in Service: 200,000 cycles
- Mechanical Life Service Cycles: 50,000,000 cycles
- Operating Temperature: -40 to 70 °C
- Dimensions (H x L x W): 36.4mm x 54.2mm x 32.5mm
- Weight: 0.2 kg
Key Features
- 10A nominal current with 3 changeover contacts.
- 220V DC coil with mechanical indicator.
- Plug-in connection for easy installation.
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Industrial: Automation systems, control panels
- Commercial: HVAC systems, lighting control
- General: Any application requiring reliable switching
Standards & Compliance
- Complies with AS/NZS 3000 for wiring rules and electrical installation.
Environmental Benefits
- Energy-efficient operation reduces overall power consumption.
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The Finder 60 Series General Purpose Relay 10A 3CO 220V DC Coil is available now for immediate purchase. Ideal for industrial and commercial applications requiring reliable switching.
