Product Name/Title: Finder 62 Series Power Relay Flange Mount 16A 2CO 110V DC Coil with Mounting Bracket
Brand: NHP
SKU: 62820008110VDC
Alternatively Known As: Power Relay, Flange Mount Relay, 16A Relay
Technical Specifications
- Nominal Current: 16 A
- Nominal Voltage AC: 250 V
- Max Rated Operation Voltage (UE AC): 400 V
- Number of Contacts: 2 CO
- Rated Switching Power at AC-1: 4000 VA
- Rated Switching Power at AC-15 (230 V): 750 VA
- Breaking Capacity at DC-1 (30 V): 16 A
- Breaking Capacity at DC-1 (110 V): 0.6 A
- Voltage Type for Actuating: DC
- Control Supply Voltage (US) at DC: 110 V
- Type of Electric Connection: Soldering flag connection
- Electrical Life at UN in Service: 100,000 cycles
- Material Contact: Silver cadmium-oxide
- Suitable for Flange Mounting: Yes
- Mechanical Life Service Cycles: 30,000,000 cycles
- Max Shock Acceleration: 15 g
- Max Shock Duration: 5 ms
- Max Vibration Acceleration: 20 m/s²
- Max Vibration Frequency Operational: 150 Hz
- Operating Temperature: -40 to 70 °C
- Dimensions (H x L x W): 36mm x 68mm x 38mm
- Weight: 0.5 kg
Key Features
- Flange mounting design for easy installation.
- High electrical life of 100,000 cycles.
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Industrial: Automation systems, control panels
- Commercial: HVAC systems, lighting control
Standards & Compliance
- Complies with AS/NZS 60950 for safety and performance standards.
Environmental Benefits
- Durable design reduces the need for frequent replacements, minimizing waste.
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The Finder 62 Series Power Relay Flange Mount 16A 2CO 110V DC Coil is available now for immediate purchase. Ideal for industrial and commercial applications.
