Product Name/Title: Finder 62 Series Power Relay Flange Mount 16A 3CO 110V AC Coil with Pushbutton plus Mechanical Ind
Brand: NHP
SKU: 62830040110VAC
Alternatively Known As: Flange Mount Power Relay, 16A Relay, AC Coil Relay
Technical Specifications
- Nominal Current: 16 A
- Nominal Voltage AC: 250 V
- Max Rated Operation Voltage: 400 V
- Rated Switching Power at AC 1: 4000 VA
- Rated Switching Power at AC 15 230 V: 750 VA
- Electrical Life: 100,000 cycles
- Mechanical Life: 10,000,000 cycles
- Operating Temperature: -40 to 70 °C
- Material of Contact: Silver cadmium-oxide
- Drive Polarization: Polarity free
- Dimensions (H x L x W): 35.8mm x 68mm x 38.2mm
- Weight: 0.5 kg
Key Features
- 16A nominal current with 3 changeover contacts.
- 110V AC coil with pushbutton and mechanical indicator.
- Suitable for flange mounting.
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal performance.
Applications
- Industrial: Automation systems, control panels
- Commercial: HVAC systems, machinery control
Standards & Compliance
- Complies with relevant Australian standards for electrical safety.
Environmental Benefits
- Energy-efficient design contributes to reduced power consumption.
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The Finder 62 Series Power Relay Flange Mount 16A 3CO 110V AC Coil is available now for immediate purchase. Ideal for industrial and commercial applications.
Non-Returnable & Non-Cancellable
