XALK02

Harmony XALD XALK, Empty control station, plastic, yellow, 1 cut-out, unmarked, UL/CSA certified


$62.00 List price: $93.00
+

Weight: 0.193 kg

Product Name/Title: Harmony XALD XALK, Empty control station, plastic, yellow, 1 cut-out, unmarked, UL/CSA certified

Brand: Clipsal

SKU: XALK02

Alternatively Known As: Empty Control Station, Harmony Control Station, Emergency Stop Control Station

Technical Specifications
  • Material: Polycarbonate
  • Cable entry: 2 knock-outs for cable entry, clamping capacity: 14-14 mm²
  • IP Rating: IP66, IP67, IP69, IP69K
  • IK Rating: IK03
  • Overvoltage category: Class II conforming to IEC 60536
  • NEMA degree of protection: NEMA 13, NEMA 4X
  • Ambient air temperature for operation: -40...70 °C
  • Dimensions (H x L x W): 70mm x 80mm x 107mm
  • Weight: 0.193 kg
Key Features
  • IP66 rated for protection against dust and water.
  • UL/CSA certified for safety and performance.
Professional Installation Requirements
  • Professional installation is recommended for optimal safety and functionality.
Applications
  • Industrial: Emergency switching off function, emergency stop function
Standards & Compliance
  • Complies with IEC 60947-5-5, UL 508, IEC 60947-1, CSA C22.2 No 14
Environmental Benefits
  • Green Premium product with packaging made from recycled cardboard.
Warranty Information

18 months warranty against manufacturing defects.

Available Now

The Clipsal Harmony XALD XALK Empty Control Station is available now for immediate purchase. Ideal for industrial applications requiring reliable emergency control solutions.

XALK02 (XALK02, 601 Kb) [Download]
