Product Name/Title: Humfree Contactor 25A, 4NC, 230V~50/60Hz
Brand: Hager
SKU: ESC426S
Alternatively Known As: Hager Humfree Contactor
Technical Specifications
- Type of contacts: 4NC
- Number of contacts: 4
- Cross-section flexible conductor: 1 - 6 mm²
- Cross-section rigid conductor: 1 - 10 mm²
- Rated current: 25 A
- Number of modules: 2
- Frequency: 50 - 60 Hz
- Rated impulse withstand voltage Uimp: 4000 V
- Rated insulation voltage Ui: 440 V
- Command voltage AC: 230 - 230 V
- Command voltage DC: 0 - 0 V
- Operating temperature: -10 - 50 °C
- Storage/transport temperature: -40 - 80 °C
- Number of mechanical operations: 100000
- Electric endurance in number of cycles: 30000
- Total power loss under IN: 6 W
- Inrush power absorbed: 3.20 VA
- Height: 83 mm
- Width: 35.75 mm
- Depth: 60 mm
- Nominal tightening torque: 1.20 - 1.20 Nm
- With switch for manual switch: No
- Dimensions (H x L x W): 83mm x 60mm x 35.75mm
- Weight: 0.2 kg
Key Features
- Reliable 4NC contact design.
- Designed for non-intensive operational use.
- Compact and sturdy construction.
Professional Installation Requirements
- Installation by a qualified electrician is recommended for safe and optimal operation.
Applications
- Ideal for use in residential and light commercial electrical systems where non-intensive applications are required.
Standards & Compliance
- Complies with relevant Australian standards for safety and performance.
Environmental Benefits
- Consistent efficient performance leading to minimal energy wastage.
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The Humfree Contactor is available now for immediate purchase, perfect for light residential and commercial applications.
