MSN163

MCB 1P 6kA C-63A 1M


$10.80 List price: $13.80
+

Weight: 0.500 kg

Product Name/Title: MCB 1P 6kA C-63A 1M

Brand: Hager

SKU: MSN163

Alternatively Known As: Miniature Circuit Breaker, MCB, Circuit Protection Device

Technical Specifications
  • Rated short-circuit breaking capacity: 6 kA
  • Rated operational voltage: 240 - 415 V
  • Rated insulation voltage: 500 V
  • Rated impulse withstand voltage: 4000 V
  • Frequency: 50 - 60 Hz
  • Nominal tightening torque: 2.80 Nm
  • Cross-section of input and output: 1 - 35 mm² for massive conductors, 1 - 25 mm² for flexible conductors
  • Dimensions (H x L x W): 83mm x 70mm x 17.5mm
  • Weight: 0.5 kg
Key Features
  • Rated current of 63 A with a breaking capacity of 6 kA.
  • Suitable for use in various climates with an operating temperature range of -25 to 70 °C.
  • IP20 ingress protection for safe indoor use.
Professional Installation Requirements
  • Professional installation by a qualified electrician is recommended for optimal safety.
Applications
  • Residential: Homes, apartments, and small buildings
  • Commercial: Offices and retail spaces
  • Industrial: Light industrial applications requiring circuit protection
Standards & Compliance
  • Complies with AS/NZS 60950 for safety of electrical equipment.
Environmental Benefits
  • RoHS and REACH compliant, contributing to reduced environmental impact.
Warranty Information

2 years warranty against manufacturing defects.

Available Now

The Hager MCB 1P 6kA C-63A 1M is available now for immediate purchase. Ideal for residential, commercial, and industrial applications requiring reliable circuit protection.
