Product Name/Title: MCB 1P 6kA D-10A 1M
Brand: Hager
SKU: MDN110P
Alternatively Known As: Miniature Circuit Breaker, MCB, Circuit Protection Device
Technical Specifications
- Rated short-circuit breaking capacity: 6 kA
- Rated operational voltage: 240-415 V
- Rated insulation voltage: 500 V
- Rated impulse withstand voltage: 4000 V
- Frequency: 50-60 Hz
- Nominal tightening torque: 2.80 Nm
- Cross-section for massive conductors: 1-35 mm²
- Cross-section for flexible conductors: 1-25 mm²
- Total power loss under IN: 1.81 W
- Dimensions (H x L x W): 85mm x 70mm x 18mm
- Weight: 0.5 kg
Key Features
- Rated current of 10 A with a breaking capacity of 6 kA.
- Suitable for use in a variety of environmental conditions with an operating temperature range of -25 to 70 °C.
- IP20 ingress protection rating.
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Residential: Homes, apartments, and electrical installations
- Commercial: Offices and retail spaces
- General: Any application requiring circuit protection
Standards & Compliance
- Complies with AS/NZS 3000 for electrical installations.
Environmental Benefits
- RoHS compliant, contributing to reduced environmental impact.
- Commitment to improving environmental performance by reducing carbon footprint.
Warranty Information
2 years warranty against manufacturing defects.
Available Now
The Hager MCB 1P 6kA D-10A 1M is available now for immediate purchase. Ideal for residential and commercial electrical installations.
