Product Name/Title: MCB 2P 15kA C-100A 3M
Brand: Hager
SKU: HMC290T
Alternatively Known As: Miniature Circuit Breaker, MCB, Circuit Protection Device
- Rated operational voltage: 415V AC
- Rated insulation voltage: 500V
- Rated impulse withstand voltage: 6000V
- Frequency: 50 - 60 Hz
- Nominal tightening torque: 3.5 - 5.0 Nm
- Electric current: Rated current 100A
- Rated short-circuit breaking capacity: 15kA
- Endurance: 4000 electric cycles, 20000 mechanical operations
- Cross-section of input/output: 1 - 70 mm² for massive conductors, 1 - 50 mm² for flexible conductors
- Dimensions (H x L x W): 90mm x 70mm x 53mm
- Weight: 0.5 kg
- 2-pole design for efficient circuit protection.
- Rated current of 100A with a breaking capacity of 15kA.
- Screw terminal connections for secure installation.
- Suitable for AC voltage supply up to 415V.
- Professional installation by a qualified electrician is recommended for optimal safety.
- Residential: Homes, apartments, and small buildings
- Commercial: Offices and retail spaces
- Industrial: Factories and manufacturing facilities
- Complies with AS/NZS 60898 for circuit protection devices.
- RoHS and REACH compliant, contributing to reduced environmental impact.
2 years warranty against manufacturing defects.
The Hager MCB 2P 15kA C-100A 3M is available now for immediate purchase. Ideal for residential, commercial, and industrial applications.
