Product Name/Title: MCB 2P 15kA D-80A 3M
Brand: Hager
SKU: HMD280T
Alternatively Known As: Miniature Circuit Breaker, MCB, Circuit Protection Device
Technical Specifications
- Type of pole: 2P
- Rated operational voltage: 415 V
- Rated insulation voltage: 500 V
- Rated impulse withstand voltage: 6000 V
- Frequency: 50 - 60 Hz
- Nominal tightening torque: 3.5 - 5.0 Nm
- Rated current: 80 A
- Electric endurance: 4000 cycles
- Mechanical operations: 20000 cycles
- Cross-section for massive conductors: 1 - 70 mm²
- Cross-section for flexible conductors: 1 - 50 mm²
- Dimensions (H x L x W): 90mm x 70mm x 53mm
- Weight: 0.5 kg
Key Features
- 2-pole design for efficient circuit protection.
- Rated short-circuit breaking capacity of 15 kA.
- Rated current of 80 A suitable for various applications.
- Screw terminal connections for secure installation.
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Residential: Homes, apartments, and small buildings
- Commercial: Offices and retail spaces
- Industrial: Factories and manufacturing facilities
Standards & Compliance
- Complies with AS/NZS 60898 for safety and performance standards.
Environmental Benefits
- RoHS and REACH compliant, ensuring reduced environmental impact.
Warranty Information
2 years warranty against manufacturing defects.
Available Now
The Hager MCB 2P 15kA D-80A 3M is available now for immediate purchase. Ideal for residential, commercial, and industrial applications.
