HMF390T

MCB 3P 10kA C-100A 4.5M


$330.00 List price: $422.00
+

Weight: 0.500 kg

Product Name/Title: MCB 3P 10kA C-100A 4.5M

Brand: Hager

SKU: HMF390T

Alternatively Known As: Miniature Circuit Breaker, MCB, Circuit Protection Device

Technical Specifications
  • Type of pole: 3P
  • Rated operational voltage: 415V AC
  • Rated insulation voltage: 500V
  • Rated impulse withstand voltage: 6000V
  • Frequency: 50 - 60 Hz
  • Rated current: 100A
  • Rated short-circuit breaking capacity: 10kA
  • Nominal tightening torque: 3.5 - 5.0 Nm
  • Electric endurance: 4000 cycles
  • Mechanical operations: 20000 cycles
  • Cross-section for massive conductors: 1 - 70 mm²
  • Cross-section for flexible conductors: 1 - 50 mm²
  • Dimensions (H x L x W): 90mm x 70mm x 80mm
  • Weight: 0.5 kg
Key Features
  • 3-pole design for three-phase systems.
  • Rated current of 100A with a breaking capacity of 10kA.
  • Screw terminal connections for secure installation.
  • High endurance with 20,000 mechanical operations.
Professional Installation Requirements
  • Professional installation by a qualified electrician is recommended for optimal safety.
Applications
  • Residential: Homes, apartments, offices
  • Commercial: Retail, hospitality, workspaces
  • Industrial: Factories, manufacturing facilities
Standards & Compliance
  • Complies with AS/NZS 60947-2 for circuit breakers.
Environmental Benefits
  • RoHS and REACH compliant, contributing to reduced environmental impact.
Warranty Information

2 years warranty against manufacturing defects.

Available Now

The Hager MCB 3P 10kA C-100A 4.5M is available now for immediate purchase. Ideal for residential, commercial, and industrial applications.
