Product Name/Title: MCB 3P 15kA C-100A 4.5M
Brand: Hager
SKU: HMC390T
Alternatively Known As: Miniature Circuit Breaker, MCB, 3 Phase Circuit Breaker, HMC390T
- Rated operational voltage: 415V AC
- Rated insulation voltage: 500V
- Rated impulse withstand voltage: 6000V
- Frequency: 50 - 60 Hz
- Nominal tightening torque: 3.5 - 5.0 Nm
- Electric current: Rated current 100A
- Endurance: 4000 electrical operations, 20000 mechanical operations
- Cross-section of input/output: 1 - 70 mm² for massive conductors, 1 - 50 mm² for flexible conductors
- Dimensions (H x L x W): 90mm x 70mm x 80mm
- Weight: 0.5 kg
- 3-pole design for three-phase systems.
- Rated current of 100A with a breaking capacity of 15kA.
- Screw terminal connections for secure installation.
- Suitable for use in various climates.
- Professional installation by a qualified electrician is recommended for optimal safety.
- Residential: Homes, apartments, and small buildings
- Commercial: Offices, retail spaces, and industrial applications
- Complies with AS/NZS 60947-2 for circuit breakers.
- RoHS and REACH compliant, contributing to reduced environmental impact.
2 years warranty against manufacturing defects.
The Hager MCB 3P 15kA C-100A 4.5M is available now for immediate purchase. Ideal for residential and commercial electrical systems.
