NDN425A

MCB 4P 10kA/15kA D-25A 4M


$250.40 List price: $320.20
+

Weight: 0.500 kg

Product Name/Title: MCB 4P 10kA/15kA D-25A 4M

Brand: Hager

SKU: NDN425A

Alternatively Known As: Miniature Circuit Breaker, MCB, 4 Pole Circuit Breaker

Technical Specifications
  • Rated current: 25 A
  • Rated service breaking capacity Ics: 15 kA
  • Rated short-circuit breaking capacity Icn: 10 kA
  • Rated insulation voltage Ui: 500 V
  • Rated impulse withstand voltage Uimp: 6000 V
  • Operating temperature: -25 to 70 °C
  • Ingress Protection (IP) class: IP20
  • Total power loss under IN: 14.75 W
  • Electrical endurance: 4000 cycles
  • Mechanical operations: 20000 cycles
  • Dimensions (H x L x W): 83mm x 70mm x 70mm
  • Weight: 0.5 kg
Key Features
  • 4-pole design for comprehensive circuit protection.
  • Rated current of 25A with a breaking capacity of 10kA/15kA.
Professional Installation Requirements
  • Professional installation by a qualified electrician is recommended for optimal safety.
Applications
  • Residential: Homes, apartments, and small buildings
  • Commercial: Offices, retail spaces, and industrial applications
Standards & Compliance
  • Complies with AS/NZS 60947 for safety and performance standards.
Environmental Benefits
  • RoHS compliant, contributing to reduced environmental impact.
Warranty Information

2 years warranty against manufacturing defects.

Available Now

The Hager MCB 4P 10kA/15kA D-25A 4M is available now for immediate purchase. Ideal for residential and commercial electrical systems.
