Product Name/Title: Moulded Case Circuit Breaker X160 1P 25kA 40A
Brand: Hager
SKU: HHA038Z
Alternatively Known As: MCCB, Moulded Case Circuit Breaker, Circuit Breaker 40A
Technical Specifications
- Rated ultimate short-circuit breaking capacity Icu: 25 kA
- Rated service breaking capacity Ics: 20 kA
- Frequency: 50 - 60 Hz
- Rated impulse withstand voltage Uimp: 8000 V
- Rated insulation voltage Ui: 690 V
- Total power loss under IN: 3.70 W
- Electric endurance: 1000 cycles
- Mechanical operations: 4000 cycles
- Nominal tightening torque: 6 - 6 Nm
- Dimensions (H x L x W): 80mm x 120mm x 100mm
- Weight: 1.5 kg
Key Features
- Rated current of 40 A with a breaking capacity of 25 kA.
- Fast tripping response time of 10 ms.
- IP4X ingress protection for enhanced safety.
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Residential: Homes, apartments, and small buildings
- Commercial: Offices, retail spaces, and industrial applications
Standards & Compliance
- Complies with AS/NZS 3000 for electrical installations.
Environmental Benefits
- Designed for energy efficiency, reducing electrical waste and enhancing safety.
Warranty Information
2 years warranty against manufacturing defects.
Available Now
The Moulded Case Circuit Breaker X160 1P 25kA 40A is available now for immediate purchase. Ideal for residential and commercial electrical safety.
