HV5823T-BLK

Nella Black 12w Surface Mounted Rotatable LED Downlight


$203.10 List price: $264.40
+

Weight: 0.500 kg

Product Name/Title: Nella Black 12w Surface Mounted Rotatable LED Downlight

Brand: Havit

SKU: HV5823T-BLK

Alternatively Known As: Rotatable LED Downlight, Surface Mounted LED Downlight, Dimmable LED Downlight

Technical Specifications
  • Power Wattage: 12W
  • Input Voltage: Available in 12v DC or 240v AC
  • Colour Temperature: 3000K, 4000K, 5500K
  • Lumens Output: 960lm, 1020lm, 1080lm
  • IP Rating: IP54
  • Beam Angle: 36°
  • Dimmable: Yes (240v Model Only)
  • Dimensions (H x L x W): 100mm x 100mm x 100mm
  • Weight: 0.5 kg
Key Features
  • Aluminium powder coated black finish
  • 36° beam angle
  • Triac Dimmable (240v Model Only)
  • IP54 rating
  • Available in 12v DC or 240v AC
Professional Installation Requirements
  • Professional installation by a qualified electrician is recommended for optimal safety.
Applications
  • Residential: Homes, apartments, offices
  • Commercial: Retail, hospitality, workspaces
  • General: Any indoor location requiring adjustable lighting
Standards & Compliance
  • Complies with AS/NZS 60598 for safety and performance standards.
Environmental Benefits
  • Energy-efficient design reduces power consumption.
Warranty Information

3 years replacement warranty for items ordered after 01/01/22.

Available Now

The Nella Black 12w Surface Mounted Rotatable LED Downlight is available now for immediate purchase. Ideal for residential and commercial spaces, combining modern design with durable performance.

Data Sheet (HV5823T_Data_Sheet_JULY23.pdf, 363 Kb) [Download]

240v Installation Instructions (HV5822-23-24-25_Installation_Instructions_MAR22.pdf, 177 Kb) [Download]

12v DC Installation Instructions (HV5822-23-24-25_12v_DC_Installation_Instructions_DEC23.pdf, 199 Kb) [Download]


Lighting Requirement Calculator







This calculator follows relevant Australian standards to ensure reliable and compliant performance. It provides an estimated recommendation based on user inputs.
Users must verify specifications before purchasing.
