DTMSW1100

NHP DIN-T Main Switch 1 Pole 100A


$75.70 List price: $100.50
+

Weight: 0.090 kg

Product Name/Title: NHP DIN-T Main Switch 1 Pole 100A

Brand: NHP

SKU: DTMSW1100

Alternatively Known As: NHP Main Switch, 1 Pole Circuit Breaker, 100A DIN Rail Switch

Technical Specifications
  • Rated Current: 100 A
  • Number of Poles: 1
  • Rated Voltage: 240 V
  • Frequency: 50-60 Hz
  • Voltage Type: AC
  • Rated Impulse Withstand Voltage: 4 kV
  • Degree of Protection: IP40
  • Connectable Conductor Cross Section: 1-50 mm²
  • Pollution Degree: 3
  • Rated Surrounding Temperature: 35 °C
  • Operating Ambient Temperature: -25 to 55 °C
  • Dimensions (H x L x W): 85mm x 75.8mm x 17.5mm
  • Weight: 0.09 kg
Key Features
  • 1 Pole design for single-phase applications.
  • Rated current of 100A suitable for various electrical loads.
  • IP40 protection rating for indoor use.
Professional Installation Requirements
  • Professional installation by a qualified electrician is recommended for optimal safety.
Applications
  • Residential: Homes, apartments, and small buildings
  • Commercial: Offices and retail spaces
  • Industrial: Light industrial applications requiring circuit protection
Standards & Compliance
  • Complies with AS/NZS 3000 for wiring rules and electrical installations.
Environmental Benefits
  • Energy efficiency and long product life.
Warranty Information

1 year warranty against manufacturing defects.

Available Now

The NHP DIN-T Main Switch 1 Pole 100A is available now for immediate purchase. Ideal for residential, commercial, and industrial applications requiring reliable circuit protection.
