DTMSW2100

NHP DIN-T Main Switch 2 Pole 100A


$120.80 List price: $160.40
+

Weight: 0.180 kg

Product Name/Title: NHP DIN-T Main Switch 2 Pole 100A

Brand: NHP

SKU: DTMSW2100

Alternatively Known As: NHP Main Switch, 2 Pole Main Switch, 100A DIN Switch

Technical Specifications
  • Rated Current: 100 A
  • Number of Poles: 2
  • Rated Voltage: 415 V
  • Frequency: 50-60 Hz
  • Voltage Type: AC
  • Rated Impulse Withstand Voltage: 4 kV
  • Degree of Protection: IP40
  • Connectable Conductor Cross Section: 1-50 mm²
  • Pollution Degree: 3
  • Rated Surrounding Temperature: 35 °C
  • Operating Ambient Temperature: -25 to 55 °C
  • Dimensions (H x L x W): 85mm x 75.8mm x 35mm
  • Weight: 0.18 kg
Key Features
  • 2 Pole design for reliable switching
  • Rated current of 100A for high capacity
  • IP40 protection rating for dust and moisture resistance
Professional Installation Requirements
  • Professional installation by a qualified electrician is recommended for optimal safety.
Applications
  • Residential: Homes, apartments, and small buildings
  • Commercial: Offices, retail spaces, and light industrial applications
Standards & Compliance
  • Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation).
Environmental Benefits
  • Energy efficiency and long product life.
Warranty Information

1 year warranty against manufacturing defects.

Available Now

The NHP DIN-T Main Switch 2 Pole 100A is available now for immediate purchase. Ideal for residential and commercial electrical systems.
