Product Name/Title: NHP DIN-T Miniature Circuit Breaker DC 6kA 1Pole 25A C Curve
Brand: NHP
SKU: DTCBDC125C
Alternatively Known As: Miniature Circuit Breaker, MCB, DC Circuit Breaker
Technical Specifications
- Rated Voltage: 240 V
- Frequency: 50-60 Hz
- Voltage Type: AC/DC
- Degree of Protection: IP40
- Rated Insulation Voltage: 440 V
- Rated Impulse Withstand Voltage: 6 kV
- Connectable Conductor Cross Section: 1-35 mm² (solid core), 1-25 mm² (multi-wired)
- Pollution Degree: 3
- Rated Surrounding Temperature Without Derating: 30 °C
- Ambient Temperature During Operating: -25-70 °C
- Dimensions (H x L x W): 86mm x 76mm x 18mm
- Weight: 0.13 kg
Key Features
- Rated current of 25 A with a C curve trip characteristic.
- 6 kA short circuit breaking capacity.
- Suitable for both AC and DC applications.
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Residential: Homes, apartments, offices
- Commercial: Retail, hospitality, workspaces
- General: Any application requiring circuit protection
Standards & Compliance
- Complies with AS/NZS 60898 for safety and performance standards.
Environmental Benefits
- Designed to operate efficiently in a wide temperature range.
Warranty Information
Standard warranty applies, please check with the manufacturer for details.
Available Now
The NHP DIN-T Miniature Circuit Breaker DC 6kA 1Pole 25A C Curve is available now for immediate purchase. Ideal for residential and commercial applications requiring reliable circuit protection.
