Product Name/Title: NHP DIN-T Miniature Circuit Breaker MCB 10kA 1 Pole 13A C Curve
Brand: NHP
SKU: DTM10113C
Alternatively Known As: Miniature Circuit Breaker, MCB, Circuit Breaker 13A, DIN Rail MCB
Technical Specifications
- Rated Current: 13 A
- Number of Poles: 1
- Trip Curve: C
- Rated Voltage: 240 V
- Frequency: 50-60 Hz
- Rated Short Circuit Breaking Capacity: 10 kA
- Degree of Protection: IP40
- Connectable Conductor Cross Section: 0.75-35 mm²
- Rated Insulation Voltage: 440 V
- Rated Impulse Withstand Voltage: 4 kV
- Pollution Degree: 3
- Rated Surrounding Temperature: 30 °C
- Dimensions (H x L x W): 85mm x 75mm x 17.5mm
- Weight: 0.12 kg
Key Features
- 10kA short circuit breaking capacity
- C curve trip characteristic for inductive loads
- IP40 protection rating
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Residential: Homes, apartments, and small buildings
- Commercial: Offices and retail spaces
- Industrial: Machinery and equipment protection
Standards & Compliance
- Complies with AS/NZS 60898 for circuit breakers.
Environmental Benefits
- Reduces the risk of electrical fires and equipment damage, promoting safety and sustainability.
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The NHP DIN-T Miniature Circuit Breaker MCB 10kA 1 Pole 13A C Curve is available now for immediate purchase. Ideal for residential, commercial, and industrial applications.
Non-Returnable & Non-Cancellable
