Product Name/Title: NHP DIN-T Miniature Circuit Breaker MCB 10kA 3 Pole 40A B Curve
Brand: NHP
SKU: DTM10340B
Alternatively Known As: Miniature Circuit Breaker, MCB, 3 Pole Circuit Breaker, 40A MCB
Technical Specifications
- Rated Current: 40 A
- Number of Poles: 3
- Trip Curve: B
- Rated Voltage: 415 V
- Frequency: 50-60 Hz
- Rated Short Circuit Breaking Capacity: 10 kA
- Degree of Protection: IP40
- Connectable Conductor Cross Section: 0.75-35 mm²
- Rated Insulation Voltage: 440 V
- Rated Impulse Withstand Voltage: 4 kV
- Pollution Degree: 3
- Rated Surrounding Temperature: 30 °C
- Ambient Temperature During Operating: -25-55 °C
- Dimensions (H x L x W): 85mm x 75mm x 52.5mm
- Weight: 0.34 kg
Key Features
- 10kA short circuit breaking capacity.
- B curve trip characteristic for general applications.
- 3 poles for three-phase systems.
- IP40 protection rating.
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Residential: Homes and apartments
- Commercial: Offices and retail spaces
- Industrial: Machinery and equipment protection
Standards & Compliance
- Complies with AS/NZS 60898 and AS/NZS 60947 for safety and performance standards.
Environmental Benefits
- Designed to enhance electrical safety and reduce fire hazards.
Warranty Information
2 years warranty against manufacturing defects.
Available Now
The NHP DIN-T Miniature Circuit Breaker MCB 10kA 3 Pole 40A B Curve is available now for immediate purchase. Ideal for protecting electrical circuits in various applications.
