NHP DIN-T Residual Current Circuit Breaker RCCB 1Pole and Neutral 80A 30mA Type A

$543.50 List price: $721.70

+ −

30 Days Return Delivery Options

Brand: NHP

Description

Product Name/Title: NHP DIN-T Residual Current Circuit Breaker RCCB 1Pole and Neutral 80A 30mA Type A

Brand: NHP

SKU: DSRCD28030A

Alternatively Known As: RCCB, Residual Current Circuit Breaker, RCD, Type A RCCB

Technical Specifications

Number of Poles: 2
Voltage Type: AC
Frequency: 50/60 Hz
Rated Current: 80 A
Leakage Current Type: A
Rated Leakage Current: 30 mA
Min Service Voltage: 117 V
Max Rated Operation Voltage (UE AC): 265 V
Rated Insulation Voltage (Ui): 440 V
Rated Impulse Withstand Voltage (Uimp): 8 kV
Rated Fault Current: 10000 A
Electrical Life at Un in Service Cycles: 10000 cycles
Degree of Protection: IP20
Connectable Conductor Cross Section (Solid Core): 50-50 mm²
Mechanical Life Service Cycles: 20000 cycles
Operating Temperature: 55 °C
Ambient Temperature During Operating: -25-55 °C
Storage Temperature: 70 °C
Pollution Degree: 2
Dimensions (H x L x W): 86mm x 76mm x 36mm
Weight: 0.25 kg

Key Features

1 Pole and Neutral configuration for effective residual current protection.
Rated current of 80A and leakage current of 30mA for enhanced safety.
DIN rail mounting for easy installation.

Professional Installation Requirements

Professional installation by a qualified electrician is recommended for optimal safety.

Applications

Residential: Homes, apartments, and small buildings
Commercial: Offices and retail spaces
Industrial: Light industrial applications requiring electrical safety

Standards & Compliance

Complies with AS/NZS 3000 for wiring rules and AS/NZS 3820 for essential safety requirements.

Environmental Benefits

Designed for efficient operation in a wide temperature range.

Warranty Information

1 year warranty against manufacturing defects.

Available Now

The NHP DIN-T Residual Current Circuit Breaker RCCB 1Pole and Neutral 80A 30mA Type A is available now for immediate purchase. Ideal for ensuring electrical safety in various applications.
