Product Name/Title: NHP DIN-T Residual Current Device Short Body w/ Overcurrent 10kA 10A 1Pole and N C Curve 10mA Type A
Brand: NHP
SKU: DSRCB1010A
Alternatively Known As: RCD, RCBO, Residual Current Circuit Breaker, Earth Leakage Circuit Breaker
- Rated Current: 10 A
- Rated Voltage: 240 V
- Rated Leakage Current: 10 mA
- Frequency: 50/60 Hz
- Trip Curve: C
- Rated Impulse Withstand Voltage: 6 kV
- Electrical Life: 10,000 cycles
- Mechanical Life: 20,000 cycles
- Degree of Protection: IP20
- Operating Temperature: -5 to 55 °C
- Dimensions (H x L x W): 86mm x 68mm x 36mm
- Weight: 0.25 kg
- 10kA short-circuit breaking capacity
- 10mA leakage current rating
- C curve tripping characteristic
- DIN rail mounting for easy installation
- Professional installation by a qualified electrician is recommended for optimal safety.
- Residential: Homes, apartments, and small buildings
- Commercial: Offices and retail spaces
- Industrial: Light industrial applications requiring overcurrent protection
- Complies with AS/NZS 61009 for safety and performance standards.
- Designed to enhance electrical safety and reduce the risk of electrical fires.
1 year warranty against manufacturing defects.
The NHP DIN-T Residual Current Device Short Body is available now for immediate purchase. Ideal for residential and commercial applications requiring reliable electrical protection.
