Product Name/Title: NHP MOD6+ Miniature Circuit Breaker MCB 6kA 3 Pole 25A C Curve
Brand: NHP
SKU: MD6M325
Alternatively Known As: Miniature Circuit Breaker, MCB, Circuit Protection Device
- Rated Current: 25 A
- Number of Poles: 3
- Trip Curve: C
- Rated Voltage: 415 V
- Frequency: 50-60 Hz
- Rated Short Circuit Breaking Capacity: 6 kA
- Degree of Protection: IP40
- Connectable Conductor Cross Section: 0.75-25 mm² (solid), 0.75-16 mm² (multi-wired)
- Rated Insulation Voltage: 440 V
- Rated Impulse Withstand Voltage: 4 kV
- Ambient Temperature: -25 to 70 °C
- Dimensions (H x L x W): 85mm x 75.8mm x 52.5mm
- Weight: 0.35 kg
- Rated current of 25A with a C curve trip characteristic.
- 6kA short circuit breaking capacity.
- IP40 protection rating.
- Professional installation by a qualified electrician is recommended for optimal safety.
- Residential: Homes, apartments, and small buildings
- Commercial: Offices and retail spaces
- Industrial: Machinery and equipment protection
- Complies with AS/NZS 60898 for safety and performance standards.
- Efficient circuit protection reduces the risk of electrical fires and equipment damage.
1 year warranty against manufacturing defects.
The NHP MOD6+ Miniature Circuit Breaker MCB 6kA 3 Pole 25A C Curve is available now for immediate purchase. Ideal for residential, commercial, and industrial applications.
