MOD6RCBO20610A

NHP MOD6 Residual Current Device - Long body w/ Overcurrent 6kA 6A 1PN C Curve 10mA Type A 36mm


$47.00 List price: $62.40
+

Brand: NHP

Product Name/Title: NHP MOD6 Residual Current Device - Long body w/ Overcurrent 6kA 6A 1PN C Curve 10mA Type A 36mm

Brand: NHP

SKU: MOD6RCBO20610A

Alternatively Known As: RCD, RCBO, Earth Leakage Circuit Breaker

Technical Specifications
  • Rated Current: 6 A
  • Rated Voltage: 240 V
  • Frequency: 50/60 Hz
  • Trip Curve: C
  • Rated Impulse Withstand Voltage: 6 kV
  • Tripping Time: 40 ms
  • Electrical Life: 10,000 cycles
  • Mechanical Life: 20,000 cycles
  • Degree of Protection: IP20
  • Operating Temperature: -5 to 55 °C
  • Dimensions (H x L x W): 86mm x 76mm x 36mm
  • Weight: 0.25 kg
Key Features
  • 6kA short circuit breaking capacity
  • 10mA rated leakage current
  • C curve trip characteristic
  • DIN rail mounting for easy installation
Professional Installation Requirements
  • Professional installation by a qualified electrician is recommended for optimal safety.
Applications
  • Residential: Homes, apartments, and small buildings
  • Commercial: Offices and retail spaces
  • Industrial: Machinery and equipment protection
Standards & Compliance
  • Complies with AS/NZS 61009 for safety and performance standards.
Environmental Benefits
  • Designed to enhance electrical safety and reduce the risk of electrical fires.
Warranty Information

Standard warranty applies.

Available Now

The NHP MOD6 Residual Current Device is available now for immediate purchase. Ideal for residential and commercial electrical safety applications.
