Product Name/Title: RCBO 1M 1P 10kA C-50A 30mA A
Brand: Hager
SKU: ADC250B
Alternatively Known As: Residual Current Circuit Breaker, RCBO, Circuit Protection Device
- Type of pole: 1P
- Curve: C
- Rated current: 50 A
- Rated residual operating current: 30 mA
- Rated short-circuit breaking capacity: 10 kA
- Rated insulation voltage: 250 V
- Rated operational voltage: 230 - 240 V
- Operating temperature: -5 to 40 °C
- Storage temperature: -40 to 70 °C
- Number of modules: 1
- Dimensions (H x L x W): 115mm x 70mm x 18mm
- Weight: 0.5 kg
- Rated current of 50 A with a residual operating current of 30 mA.
- 10 kA short-circuit breaking capacity.
- IP20 ingress protection rating.
- Professional installation by a qualified electrician is recommended for optimal safety.
- Residential: Homes, apartments, offices
- Commercial: Retail, hospitality, workspaces
- General: Electrical safety in various installations
- Complies with AS/NZS 3000 for electrical installations.
- RoHS compliant, contributing to reduced environmental impact.
2 years warranty against manufacturing defects.
The Hager RCBO 1M 1P 10kA C-50A 30mA A is available now for immediate purchase. Ideal for residential and commercial electrical safety applications.
