HV3283T-SS316

Ridge 316 Stainless Steel LED Step Light


$218.50 List price: $284.50
+

Weight: 0.500 kg

Product Name/Title: Ridge 316 Stainless Steel LED Step Light

Brand: Havit

SKU: HV3283T-SS316

Alternatively Known As: 316 Stainless Steel Step Light, Outdoor LED Step Light

Technical Specifications
  • Input Voltage: 12V DC
  • IP Rating: IP54
  • Built-in LED: 6W
  • Lumens Output: 480lm, 500lm, 520lm
  • Colour Temperature: 3000K, 4000K, 5500K
  • Dimensions (H x L x W): 50mm x 200mm x 100mm
  • Weight: 0.5 kg
Key Features
  • 316 Stainless Steel construction for durability and corrosion resistance.
  • TRI Colour options: 3000K, 4000K, 5500K.
  • Built-in 6W LED with high lumen output.
Professional Installation Requirements
  • Must be used with a suitable 12V DC LED driver; professional installation is recommended.
Applications
  • Residential: Gardens, pathways, outdoor stairs
  • Commercial: Outdoor spaces, hospitality venues, public areas
Environmental Benefits
  • Energy-efficient built-in LED reduces power consumption.
Warranty Information

3 years replacement warranty for items ordered after 01/01/22.

Available Now

The Ridge 316 Stainless Steel LED Step Light is available now for immediate purchase. Ideal for enhancing outdoor safety and aesthetics.

Data Sheet (HV3283_Data_Sheet_JAN23.pdf, 604 Kb) [Download]

Installation Instructions (HV3282_HV3283_Installation_Instructions_FEB22.pdf, 179 Kb) [Download]
