Product Name/Title: S+S CA7 Contactor 5.5kW 3Pole 110VAC Coil 1NC Contact Auxiliary
Brand: NHP
SKU: CA71201110VACU
Alternatively Known As: Power Contactor, AC Contactor, Motor Contactor
Technical Specifications
- Number of normally open contacts: 3
- Number of normally closed contacts: 0
- Rated operation current at AC 3, 400 V: 12 A
- Rated operation power at AC 3, 400 V: 5.5 kW
- Rated operation current at AC 1, 400 V: 32 A
- Max rated operation voltage: 690 V
- Control supply voltage at AC 50 Hz: 110 V
- Number of auxiliary contacts (normally closed): 1
- Rated operation current at AC 3, 690 V: 7 A
- Rated operation power at AC 3, 690 V: 5.5 kW
- Rated operation power at AC 4, 400 V: 3 kW
- Control supply voltage at AC 60 Hz: 120 V
- Power consumption AC coil pickup: 75 VA
- Power consumption AC coil hold-in: 9.5 VA
- Type of electrical connection: Screw connection
- Rated operation current at AC 4, 400 V: 6.6 A
- Degree of protection: IP2X
- Mounting method: DIN-rail/screw
- Dimensions (H x L x W): 81mm x 86.5mm x 45mm
- Weight: 0.39 kg
Key Features
- 5.5 kW rated operation power
- 3 pole configuration with 1 normally closed auxiliary contact
- Rated for 110 VAC control supply voltage
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Industrial: Motor control and automation systems
- Commercial: HVAC systems and lighting control
Standards & Compliance
- Complies with relevant Australian standards for electrical equipment.
Environmental Benefits
- Energy-efficient operation reduces overall power consumption.
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The S+S CA7 Contactor 5.5kW 3Pole 110VAC Coil is available now for immediate purchase. Ideal for industrial and commercial applications.
