Product Name/Title: S+S CA8 Auxiliary Contact with 2NC Contact
Brand: NHP
SKU: CA8P02
Alternatively Known As: Auxiliary Contact Block, Mini Auxiliary Contact
Technical Specifications
- Number of contacts: 2 NC
- Rated insulation voltage: 690 V
- Rated operation current at 40°C: 10 A
- Rated operation current at AC 15 24 V: 3 A
- Rated operation current at AC 15 120 V: 3 A
- Rated operation current at AC 15 240 V: 2 A
- Rated operation current at AC 15 400 V: 1.2 A
- Rated operation current at DC 13 24 V: 2.3 A
- Rated operation current at DC 13 110 V: 0.55 A
- Rated operation current at DC 13 220 V: 0.27 A
- Minimum contact rating current: 2 mA
- Minimum contact rating voltage: 15 V
- Mounting method: Top mounting
- Dimensions (H x L x W): 30mm x 60mm x 50mm
- Weight: 0.2 kg
Key Features
- Mini auxiliary contact with 2 normally closed contacts.
- Rated insulation voltage of 690 V.
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Industrial: Control circuits in machinery and equipment
- Commercial: Automation systems and electrical panels
Standards & Compliance
- Complies with relevant Australian standards for electrical components.
Environmental Benefits
- Designed for energy efficiency in control applications.
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The NHP S+S CA8 Auxiliary Contact with 2NC Contact is available now for immediate purchase. Ideal for industrial and commercial automation applications.
