CA8P22

S+S CA8 Auxiliary Contact with 2NO Contacts and 2NC Contact

$95.40 List price: $126.70
+ −
30 Days Return Delivery Options
Brand: NHP

Product Name/Title: S+S CA8 Auxiliary Contact with 2NO Contacts and 2NC Contact

Brand: NHP

SKU: CA8P22

Alternatively Known As: Auxiliary Contact Block, Mini Auxiliary Contact

Technical Specifications
  • Number of NO contacts: 2
  • Number of NC contacts: 2
  • Rated insulation voltage: 690 V
  • Rated operation current at 40°C: 10 A
  • Rated operation current at AC 15, 24 V: 3 A
  • Rated operation current at AC 15, 120 V: 3 A
  • Rated operation current at AC 15, 240 V: 2 A
  • Rated operation current at AC 15, 400 V: 1.2 A
  • Rated operation current at DC 13, 24 V: 2.3 A
  • Rated operation current at DC 13, 110 V: 0.55 A
  • Rated operation current at DC 13, 220 V: 0.27 A
  • Minimum contact rating current: 2 mA
  • Minimum contact rating voltage: 15 V
  • Rated operation current at AC 15, 230 V: 2 A
  • Mounting method: Top mounting
  • Dimensions (H x L x W): 100mm x 75mm x 50mm
  • Weight: 0.5 kg
Key Features
  • 2 Normally Open (NO) and 2 Normally Closed (NC) contacts.
  • Rated insulation voltage of 690 V.
  • Top mounting method for easy installation.
Professional Installation Requirements
  • Professional installation by a qualified electrician is recommended for optimal safety.
Applications
  • Industrial: Control circuits, automation systems
  • Commercial: Electrical panels, machinery control
Standards & Compliance
  • Complies with AS/NZS 3820 for essential safety requirements for electrical equipment.
Environmental Benefits
  • Designed for energy efficiency in electrical systems.
Warranty Information

1 year warranty against manufacturing defects.

Available Now

The S+S CA8 Auxiliary Contact with 2NO and 2NC Contacts is available now for immediate purchase. Ideal for industrial and commercial applications.
