Product Name/Title: S+S CA8 Auxiliary Contact with 4NC Contacts
Brand: NHP
SKU: CA8P04
Alternatively Known As: Auxiliary Contact Block, Mini Auxiliary Contact
Technical Specifications
- Number of Contacts: 4 NC
- Rated Insulation Voltage: 690 V
- Rated Operation Current at 40°C: 10 A
- Rated Operation Current at AC 15 24 V: 3 A
- Rated Operation Current at AC 15 120 V: 3 A
- Rated Operation Current at AC 15 240 V: 2 A
- Rated Operation Current at AC 15 400 V: 1.2 A
- Rated Operation Current at DC 13 24 V: 2.3 A
- Rated Operation Current at DC 13 110 V: 0.55 A
- Rated Operation Current at DC 13 220 V: 0.27 A
- Min Contact Rating Current: 2 mA
- Min Contact Rating Voltage: 15 V
- Rated Operation Current at AC 15 230 V: 2 A
- Mounting Method: Top mounting
- Dimensions (H x L x W): 100mm x 75mm x 50mm
- Weight: 0.5 kg
Key Features
- 4 normally closed contacts for reliable operation.
- Rated insulation voltage of 690 V.
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Industrial: Automation systems, control panels
- Commercial: Electrical installations requiring auxiliary contacts
Standards & Compliance
- Complies with relevant Australian standards for electrical safety.
Environmental Benefits
- Energy-efficient design contributes to reduced power consumption.
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The S+S CA8 Auxiliary Contact with 4NC Contacts is available now for immediate purchase. Ideal for industrial and commercial electrical installations.
